Custom Part Carbonless Forms Boxes
Custom boxes for carbonless form sets — 2-, 3- and 4-part NCR in A4, A5 and letter — sized to the set count and printed with the form title, from 100. Dieline and price the same working day.
A box that keeps five hundred sets square and in order
- Board
- 20–24pt boxboard lidded; E flute tuck cartons
- Builds
- Two-piece lidded, tuck-end, tear-front dispenser
- Sizing
- Sheet plus 3 mm a side; stack plus 5 mm; A4, A5, letter, half-letter
Get a price for Part Carbonless Forms Boxes
Send the size and quantity — we reply the same working day with a price, a dieline and a date. Artwork optional at this stage.
- Free dielineThe flat drawing comes with the quote, before you commit.
- Proof before pressNothing is printed until you have seen it laid on the dieline.
- Die kept for reordersTooling is paid once. Every reorder skips straight to press.
- Quoted in four marketsUS, UK, Canada and Australia, in the delivery currency.
Sizing to the set
The box is cut to the sheet size plus 3 mm a side and the stack height plus 5 mm. Sets that are glued at the head into books need a little more room for the spine.
| A5 / half-letter, 2-part | 100 sets about 22 mm; 250 sets about 55 mm |
|---|---|
| A4 / letter, 3-part | 100 sets about 32 mm; 250 sets about 80 mm |
| A4 / letter, 4-part | 100 sets about 42 mm; 250 sets about 105 mm |
Lidded box, tuck carton, or tear-front dispenser
- Two-piece lidded box in 20–24pt board — the stock box for a print shop selling sets over the counter.
- Tuck-end carton in E flute — cheaper, ships flat, right for a customer's own supply.
- Tear-front dispenser — a perforated panel on the front so sets are pulled one at a time from a shelf.
Print that identifies the form
The end panel is what is read on a shelf: form title, part count, sequence numbers, the customer name. One or two colors on white board does it; full color is rarely worth it here. A reserved panel takes a printed or handwritten label for the number range inside. Our business forms packaging range covers the notepad and receipt-book boxes that sit beside these.
Keeping carbonless paper flat and dry
NCR paper curls in damp air and the coating marks under pressure. A rigid box with a close-fitting lid keeps the stack flat; a loose box lets the top sets curl. Board with a plain unvarnished interior avoids any transfer to the top sheet. Boxes are packed in a shipper for freight, not sent on their own.
Do not shrink-wrap NCR sets tightly inside the box. The pressure can mark the coated sheets.
Print shops and the stock-box strategy
A commercial printer sells dozens of forms in three or four sizes. Four stock boxes with a printed label panel cover every job, and a run of 100 to 500 of each is a year's supply. The dies are kept and the boxes reorder as they run down.
Part Carbonless Forms Boxes — specification
The rows that are specific to this build first, then what applies to every job we run. Anything not listed is a question, not a limit — send the brief.
This build
- Board
- 20–24pt boxboard lidded; E flute tuck cartons
- Builds
- Two-piece lidded, tuck-end, tear-front dispenser
- Sizing
- Sheet plus 3 mm a side; stack plus 5 mm; A4, A5, letter, half-letter
- 1–2 colors; end-panel title; reserved label panel
- Interior
- Plain, unvarnished, so nothing transfers to the top sheet
- Supply
- Flat; lidded boxes fold at the bench
- Minimum
- 100 boxes
On every job
- Print process
- Digital below about a thousand, offset above it. Both sides as standard on cards, tags and leaflets.
- Color
- CMYK with spot colors for a brand match. Uncoated and cotton stocks print noticeably lighter than coated ones.
- Tolerance
- Trim plus or minus 1 mm guillotined, plus or minus 0.5 mm die-cut. Anything over about 170gsm is creased before folding.
- Tooling
- A die only where the piece is shaped, perforated or drilled, made once and kept. A plain rectangle needs none.
- Food contact
- Food-safe inks on menus and counter print that will be handled where food is served.
- Sustainability
- Uncoated and unlaminated stocks recycle without separation, and FSC papers are available across the range.
- Artwork
- Vector PDF or AI, 3 mm bleed, 4 mm safe area, fonts outlined. We check every file and send a proof before press.
- Dieline
- Supplied free with the quote, before you commit. Yours whether or not you order.
- Sample
- A plain unprinted sample at the finished size on request, for fit and construction.
- Reorders
- Skip the tooling and go straight to press at a lower unit price.
- Lead time
- Quoted with the price against your fill date rather than promised before we have seen the spec.
- Markets
- United States, United Kingdom, Canada, Australia — priced in the delivery currency, freight included.
Boards and films we build part carbonless forms boxes on
Sheet print is judged in the hand more than a box is: the weight, the surface and whether a pen works on it. These are the stocks we run for cards, folders, leaflets and stationery.
Coated card 300–400gsm
The workhorse. Sharp full-color print, matte or gloss, laminated where it is handled. Does not take a pen unless the finish is matte.
300–400gsmUncoated card
No clay coat. Colors read softer and warmer, a deboss goes deeper, and it writes on with anything. Photographs lose punch.
300–400gsmCotton and textured card
Soft, thick and fibrous. Takes a deep blind deboss and reads as an invitation. Foil sits beautifully; four-color does not.
400–700gsmDuplexed card
Two sheets bonded, often with a colored core, for a very thick card with a visible colored edge. The heaviest thing we print.
600–900gsmText paper 100–170gsm
Leaflets, folder inners and booklet pages. Folds without cracking and takes a full-color print on both faces.
100–170gsmManila and kraft paper
Unbleached, tan, and cheap. One or two colors read well; white ink gives a light mark. Envelopes, folders and tags.
90–300gsmSynthetic stock
Polypropylene sheet for tags and cards that get wet, torn or handled outdoors. Prints like paper and does not soften.
200–400 micronBoard-backed
A printed face laminated to grayboard, for a rigid card, a folder back or a display that has to stand up on its own.
1–2 mm boardNot sure which? Say what goes in it and where it is sold — the material follows from that. Our notes on recycled, recyclable and compostable cover which claims each stock can honestly carry.
- 01
Send what you have
A dimension, a photograph beside a ruler, or the product itself. No technical drawing needed — that part is ours.
- 02
We quote and draw
A price, a dieline and a date come back together. If a different build would suit the product better, that is in the reply too.
- 03
Approve the dieline
The flat drawing is yours to check: which panel is the front, where the folds fall, how deep the cavity really is.
- 04
Artwork on the dieline
You place your design on the flat we sent, or we place it for you, and you see a proof before anything goes to press.
- 05
A sample if you want one
A plain unprinted sample at the finished size shows fit and construction — the things a drawing cannot.
- 06
Cut, printed, shipped
The die is cut once and kept, so every reorder skips the tooling and goes straight to press at a lower unit price.
Format
Vector PDF or AI where possible. Raster artwork at 300dpi at final size, in CMYK.
Bleed
3 mm past every trim line, so a fraction of drift on the cutter never leaves a white edge.
Safe area
Keep type and anything important 4 mm inside the cut and away from every fold.
Color
Convert to CMYK before sending. Uncoated stock prints lighter; a spot color is the only exact match.
Fonts
Outline them or supply the files. A missing font substitutes silently and the proof will not match.
Barcodes
On a light, matte, unvarnished patch with the quiet zone clear — a code on gloss fails the scanner.
Not set up that way? Send it anyway — fixing a file is a short conversation, and we check every one before press. Our guide to preparing print files covers each point.
Sheet print takes the widest range of finishes of anything we make.
Matte lamination
Soft, fingerprint-resistant, and it still takes a pen. The default on anything handled.
Gloss lamination
Maximum color depth. Shows every fingerprint and refuses a ballpoint.
Hot foil
Gold, rose gold, silver, holographic or a color. The block is small so the die is cheap.
Emboss and deboss
Deepest on uncoated and cotton stocks; shallow and prone to cracking on gloss coated.
Spot UV
A gloss shape on a matte laminate. Best on a dark ground where the contrast reads.
Edge paint and colored core
Color on the cut edge of a thick or duplexed card. Only seen when the card is picked up, which is the point.
Soft-touch
A velvet laminate on a cover or a folder. Marks on white; excellent on dark.
Uncoated and textured
No film at all. Writes on, debosses deeply, and reads as considered rather than cheap.
Not sure which suits the shelf it sells from? Say where the product is sold and we suggest one — our notes on specialty finishes show them on real boxes.
Sizing printed sheets, folds and the grain: part carbonless forms boxes
A printed piece is specified flat and finished folded, and the difference between the two is where mistakes live. Send the finished size you want and we work back to the flat.
- Finished size
- The size after folding and trimming. A6, A5, A4, DL, US letter and legal are standard; anything else is cut on its own die.
- Bleed and safe area
- 3 mm of artwork past every trim edge, and nothing important within 4 mm inside it. The guillotine drifts by a fraction on every stack.
- Grain direction
- Paper folds cleanly along the grain and cracks across it. We set the grain to the fold, which is why a sheet is not simply cut from the biggest sheet available.
- Fold allowance
- On a roll fold or a gate fold, the inner panels are cut a millimeter or two shorter so the piece closes flat.
- Creasing
- Anything over about 170gsm is creased before folding. Without it the fold cracks and the coating flakes along the line.
- Trim tolerance
- Plus or minus 1 mm guillotined, plus or minus 0.5 mm die-cut.
Not sure your numbers are right? Send the product dimensions rather than the box dimensions and we work the box out — the full method is in our guide to measuring for a box.
Interactive · five steps · no sign-up
Spec your Part Carbonless Forms Boxes
Pick a shape, type a size, choose a stock and a finish. The preview on the left redraws as you go, and the spec lands with us exactly as you set it.
Frequently asked questions
Got a question about part carbonless forms boxes? The answers below cover what we get asked most. If yours is not here, send it with a brief, message us on WhatsApp, or call +1 503-461-4788 — we reply the same working day.
What sizes of form box do you make?
A4, A5, letter and half-letter as standard, sized to the part count and set count, and any custom form size.
How do I work out the box depth?
Roughly 0.1 mm per sheet: a 3-part set is about 0.32 mm, so 250 sets is about 80 mm. We size it from the count you give us.
Can sets be pulled one at a time?
Yes, from a tear-front dispenser with a perforated panel.
Will the paper curl in the box?
Not in a close-fitting lidded box. Loose boxes let the top sheets curl in damp air.
Can the box be printed with the form title?
Yes, on the end panel in one or two colors, with a reserved panel for a label carrying the number range.
What is the minimum order?
100 boxes.
Do they ship flat?
Yes. Lidded boxes fold at the bench; tuck cartons pop open.
Can one box serve many forms?
Yes, with a blank label panel. A print shop usually keeps three or four stock sizes.
Should I shrink-wrap the sets inside?
Loosely if at all. Tight wrap marks the coated sheets.
Can the box hold glued books rather than loose sets?
Yes, with a little more room for the spine. Tell us which.
Do you keep the die?
Yes, per size, so reorders skip the tooling.
Do you ship outside the US?
Yes, to the United States, United Kingdom, Canada and Australia, quoted in the delivery currency.
