Custom Pharmaceutical Boxes
Every other carton on this site exists to sell something. This one exists to carry information accurately, survive a supply chain that will audit it, and be opened by someone who may be unwell. Design comes fourth.
Get a price for Pharmaceutical Boxes
Send the size and quantity — we reply the same working day with a price, a dieline and a date. Artwork optional at this stage.
- 4styles in this range, each with its own page and price
- 100unit minimum on every style, printed or plain
- 4markets quoted in the delivery currency
- ±1mmcutting tolerance on folding board, checked on a sample
4 styles in this range
Styles we make in this range
Every one below is written up, priced and dielined. Tap a style to see how it is built.
01See the build →Cardboard Pillow Boxes
Custom cardboard pillow boxes
02See the build →Dental Lab Boxes
Custom dental lab boxes for cases traveling between practice and lab
03See the build →Kraft Pillow Boxes
A pillow box is one piece of board with two curved die-cuts.
04See the build →Medical Brochures Boxes
Custom medical brochure boxes
Side by side
Which pharmaceutical boxes style fits
| Style | Board | Build | Minimum | |
|---|---|---|---|---|
| Cardboard Pillow Boxes | 250–350 gsm or 16pt; kraft or coated white | One-piece pillow with curved ends; window optional | 100 boxes | Open → |
| Dental Lab Boxes | E flute case boxes; B flute for solo transit; wrapped grayboard finished-case boxes | Crash-lock carton, lidded tray, rigid presentation box; reusable option | 100 boxes | Open → |
| Kraft Pillow Boxes | 250–350gsm; kraft, kraft-look coated or white | One-piece pillow box with curved die-cut ends | 100 boxes | Open → |
| Medical Brochures Boxes | 20–24pt laminated boxboard holders; E flute shipping cartons; heavy board folders | Counter dispenser, pocket folder, lidded kit box, shipping carton | 100 units | Open → |
Start from the leaflet, not the product
The single most common reason a pharmaceutical carton has to be redrawn is that it was sized around the bottle or blister and the patient information leaflet would not fit. A folded leaflet is stiff, it does not compress, and it takes real space along one wall.
Measure the folded leaflet at its thickest and add it to the pack depth before anything else. If the leaflet is being printed at the same time, fix its fold pattern first and let the carton follow.
A leaflet that has to be forced in will be forced in crooked on a filling line, and the carton will not close square.
Tamper evidence has to be designed in, not stuck on
Whichever you choose, decide before artwork. A tamper flap changes the dieline, and the tear line will run straight through whatever artwork sits on that panel.
- Glued end flaps. The carton cannot be opened without visible fiber tear. Cheapest and most common; needs a filling line that can glue.
- Tamper-evident tuck. A perforated flap that tears on first opening. Works on hand filling, which is why small runs use it.
- Seal label over the tuck. Flexible, but it is a second component to buy, apply and account for.
Braille is embossed after printing, and it needs room
Braille on a medicine carton is embossed into the board, usually on the largest free panel. The dots need a clear area with nothing behind them — no varnish, no heavy solid, and no crease within a few millimeters, because a fold flattens the dots.
Board choice matters here more than anywhere else on the site. Very light board will not hold the dot height; heavily coated board can crack around it. This is one of the few cases where we will push back on a board specification.
Leave the coding window empty
A data matrix printed onto gloss varnish will fail verification under a scanner even when it looks perfect to the eye. Reserve a matte, unvarnished, light-colored patch and keep artwork out of it entirely.
| Batch number | Applied on the line, usually inkjet |
|---|---|
| Expiry date | Same pass, same window |
| 2D data matrix | Needs a light, matte, unvarnished patch |
| Barcode | Printed with the carton, quiet zone protected |
Where these cartons overlap with everything else
Supplement, dental and device packs use the same construction and the same discipline, without the same rules. If your product is a supplement rather than a licensed medicine, you still benefit from the coding window and the leaflet allowance — and you can borrow the finishes from our shelf-facing retail cartons without compromising anything.
Across the range
What every pharmaceutical boxes job runs on
Boards
- Natural kraft
- White SBS
- E and B flute
- Wrapped grayboard
- Food-grade board
- Recycled content
Chosen from what goes in the box and how far it travels. Our notes on recyclable and compostable stocks say which claims each board can carry.
Finishes
- Matte
- Gloss
- Soft-touch
- Foil
- Emboss
- Spot UV
- Kraft
- Textured
Each one is a decision about light on a shelf — the specialty finishes range shows them on real boxes.
Artwork
- Vector PDF or AI, fonts outlined
- 3 mm bleed, 4 mm safe area
- CMYK; a spot color where a match must hold
- Proof on the dieline before press
Files not set up that way are fine — see the guide to preparing print files.
Interactive · five steps · no sign-up
Build your Pharmaceutical Boxes in 3D
Pick a shape, type a size, choose a board and a finish. The preview on the left redraws as you go, and the spec lands with us exactly as you set it.
Frequently asked questions
Got a question about pharmaceutical boxes? The answers below cover what we get asked most. If yours is not here, send it with a brief, message us on WhatsApp, or call +1 503-461-4788 — we reply the same working day.
Can you print the batch and expiry for me?
No — those are applied at fill, on your line. What we do is reserve and protect the area so the code scans.
Does Braille add much to the cost?
It adds an embossing pass and a tooling charge. On a small run it is noticeable; on a repeat run the tooling is already paid for.
Do I need a leaflet inside the carton?
That depends on your product and market. Tell us whether there is one and how it folds, and we size around it.
Will you supply a dieline before printing?
Always, on every job. Nothing goes to press without you seeing the flat.
What is the minimum order?
100 cartons, any closure.
Why must the coding window be unvarnished?
A data matrix printed onto gloss varnish fails verification under a scanner even when it looks perfect to the eye.
Can you print the batch and expiry for me?
No — those are applied at fill, on your line or your filler's. What we do is reserve and protect the area so the code scans.
Does Braille add much to the cost?
It adds an embossing pass and a tooling charge. On a small run it is noticeable; on a repeat run the tooling is already paid for.
Do I need a leaflet inside the carton?
That depends on your product and market, not on us. Tell us whether there is one and how it folds, and we will size around it either way.
Will you supply a dieline before printing?
Always, on every job on this site. Nothing goes to press without you seeing the flat.
