Custom Hang Tab Box with Window
Custom hang tab boxes with a window cut where the product shows best, sized to your item and the retailer's hook, from 100. We draw the window and the tab on one dieline and send it with the price the same working day.
Let the product do the selling from the hook
- Board
- 18–24pt folding boxboard
- Builds
- Tuck end with integral tab; five-panel doubled tab; tray and sleeve
- Window
- Die-cut, rounded corners; PET, paper-based or open
Get a price for Hang Tab Box with Window
Send the size and quantity — we reply the same working day with a price, a dieline and a date. Artwork optional at this stage.
- Free dielineThe flat drawing comes with the quote, before you commit.
- Proof before pressNothing is printed until you have seen it laid on the dieline.
- Die kept for reordersTooling is paid once. Every reorder skips straight to press.
- Quoted in four marketsUS, UK, Canada and Australia, in the delivery currency.
Where to cut the window
Over the part of the product that explains it — the color of the cable, the head of the tool, the texture of the cosmetic. Not centered on the panel by default. The window should stop 8–10 mm from every edge and fold so the panel keeps its strength, and it should not run into the hang tab area, where the board is doing the carrying. We place it on the dieline from a photograph of the product and adjust once on the sample.
Film, no film, or a paper window
Film is applied flat before the box is glued, so the window is set before the box exists. It cannot be added afterwards.
| Clear PET film, glued inside | Standard; keeps dust out, product touchable through it |
|---|---|
| Open die-cut, no film | Cheapest; suits products that can be touched — brushes, textiles |
| Paper-based window film | For a mono-material pack that recycles as paper |
| Anti-scuff PET | Where the product would mark a standard film in transit |
Keeping the panel strong around a hole
- A window removes board from the panel that supports the tab; keep at least 12 mm of board between the window and the tab fold.
- Round the window corners — a sharp corner starts a tear.
- On a heavy product, put the window on the front and the hang tab on a doubled panel behind it.
- Board at 18pt or heavier once a window is cut; 16pt with a window flexes.
Products it is built for
Small electronics and accessories, cosmetics and beauty tools, hardware, toys, craft supplies, pet accessories. Anything whose appearance is the reason to buy. Our hanging retail boxes without a window cover the same peg-hook carton where the print is doing the selling instead.
Print around a window
The window takes the center of attention, so print around it should frame rather than compete: the name above, one claim below, the barcode on the back. A colored inside print visible through the window behind the product is a small cost with a large effect on how the product reads.
Send a product photograph with the brief. Placing the window from a photo is faster and more accurate than from dimensions alone.
Hang Tab Box with Window — specification
The rows that are specific to this build first, then what applies to every job we run. Anything not listed is a question, not a limit — send the brief.
This build
- Board
- 18–24pt folding boxboard
- Builds
- Tuck end with integral tab; five-panel doubled tab; tray and sleeve
- Window
- Die-cut, rounded corners; PET, paper-based or open
- Hang tab
- Euro-slot, round or sombrero; positioned over the center of mass
- Full color outside; inside print behind the window optional
- Placement
- Window set from a product photo on the dieline
- Minimum
- 100 boxes
On every job
- Print process
- Digital below about a thousand, offset above it. One side or both, with spot colors where a match has to hold.
- Color
- CMYK as standard. Uncoated and kraft stocks print lighter and warmer; a spot color is the only exact match.
- Tolerance
- Cutting plus or minus 1 mm, creasing plus or minus 0.5 mm, confirmed on a plain sample before the run.
- Tooling
- A cutting die per size, made once and kept. Foil and emboss dies per artwork, also kept.
- Food contact
- Food-grade board and inks where the carton touches food, with the interior left plain.
- Sustainability
- Mono-material board wherever the product allows; recycled-content and FSC stocks; no claim printed the pack does not earn.
- Artwork
- Vector PDF or AI, 3 mm bleed, 4 mm safe area, fonts outlined. We check every file and send a proof before press.
- Dieline
- Supplied free with the quote, before you commit. Yours whether or not you order.
- Sample
- A plain unprinted sample at the finished size on request, for fit and construction.
- Reorders
- Skip the tooling and go straight to press at a lower unit price.
- Lead time
- Quoted with the price against your fill date rather than promised before we have seen the spec.
- Markets
- United States, United Kingdom, Canada, Australia — priced in the delivery currency, freight included.
Boards and films we build hang tab box with window on
A folding carton is one sheet of board, so the board is the product. These are the stocks we run for cartons, what each is good at, and where it lets you down.
Natural kraft
Unbleached folding board. Warm, hides marks, costs least. Mutes color — one or two flat colors print well, photographs do not.
250–350gsm sleeves; 14–24pt cartonsWhite SBS
Solid bleached sulfate: bright, coated, the retail carton standard. Takes accurate color and every finish. Shows scuffs sooner than kraft.
14–24ptWhite lined chipboard
A recycled gray core under a white printing face. Cheaper than SBS and slightly duller; the back of the sheet stays gray.
16–24ptKraft-look coated
A kraft face over a coated inner. The natural look with a barrier behind it — the answer where oil, grease or moisture would mark plain kraft.
14–20ptRecycled-content board
Post-consumer fiber with a gray-brown cast. Right for outers and inner components; poor for bright whites and photography.
16–22ptMicro-flute E and F
A fine corrugated layer where a carton needs structure it cannot get from board — a large panel, a heavy product, a box that ships alone.
E 1.5 mm; F 0.8 mmUncoated and textured
No clay coat, or a linen or laid grain. Print reads softer and warmer; a deboss goes deeper. Photographs do not sit well on it.
280–350gsmMetallised and pearlescent
A metallic or pearl face for a shelf that needs to catch light. Costly, and it fights a photograph — a mark or a pattern suits it better.
16–20ptNot sure which? Say what goes in it and where it is sold — the material follows from that. Our notes on recycled, recyclable and compostable cover which claims each stock can honestly carry.
- 01
Send what you have
A dimension, a photograph beside a ruler, or the product itself. No technical drawing needed — that part is ours.
- 02
We quote and draw
A price, a dieline and a date come back together. If a different build would suit the product better, that is in the reply too.
- 03
Approve the dieline
The flat drawing is yours to check: which panel is the front, where the folds fall, how deep the cavity really is.
- 04
Artwork on the dieline
You place your design on the flat we sent, or we place it for you, and you see a proof before anything goes to press.
- 05
A sample if you want one
A plain unprinted sample at the finished size shows fit and construction — the things a drawing cannot.
- 06
Cut, printed, shipped
The die is cut once and kept, so every reorder skips the tooling and goes straight to press at a lower unit price.
Format
Vector PDF or AI where possible. Raster artwork at 300dpi at final size, in CMYK.
Bleed
3 mm past every trim line, so a fraction of drift on the cutter never leaves a white edge.
Safe area
Keep type and anything important 4 mm inside the cut and away from every fold.
Color
Convert to CMYK before sending. Uncoated stock prints lighter; a spot color is the only exact match.
Fonts
Outline them or supply the files. A missing font substitutes silently and the proof will not match.
Barcodes
On a light, matte, unvarnished patch with the quiet zone clear — a code on gloss fails the scanner.
Not set up that way? Send it anyway — fixing a file is a short conversation, and we check every one before press. Our guide to preparing print files covers each point.
Every finish here is a decision about light on a shelf, not about luxury.
Matte lamination
Reads considered, hides marks, takes a ballpoint.
Gloss lamination
Lifts color; glares under shop lighting.
Soft-touch
Velvet in the hand; shows fingerprints in a bag.
Hot foil
Real metal leaf — the most reliable premium signal.
Emboss / deboss
Shape with no ink; works in the dark.
Spot UV
Gloss shapes on a matte field.
Uncoated kraft
Warm, natural, mutes color.
Textured stock
Texture in the paper; cannot scuff off.
Not sure which suits the shelf it sells from? Say where the product is sold and we suggest one — our notes on specialty finishes show them on real boxes.
Sizing a folding carton so the die comes out right: hang tab box with window
Measure the product, not the box it is in now. A carton is built around what has to fit inside it, assembled — cap on, lid fitted, folded if it folds — at its widest point in each direction. Send those three numbers and say which is which.
- Length x width x height
- Internal, always. External dimensions include the board and are what the carrier measures, not what the product needs.
- Clearance
- 2–3 mm a side for a snug fit; more where an insert or void fill goes in. A carton cut exactly to the product is slow to pack and transmits every knock.
- Board thickness
- Heavier board takes internal space from the product. It matters most on small boxes, where four walls of 24pt is a real share of the cavity.
- Varies between batches?
- Glass, textiles, molded parts and cured soap all do. Measure several and build to the largest.
- Cutting tolerance
- Plus or minus 1 mm on folding board. Confirmed on a plain sample before the run.
- Units
- Metric or imperial, as long as you say which. Mixing them in one spec is where mistakes happen.
Not sure your numbers are right? Send the product dimensions rather than the box dimensions and we work the box out — the full method is in our guide to measuring for a box.
Interactive · five steps · no sign-up
Build your Hang Tab Box with Window in 3D
Pick a shape, type a size, choose a board and a finish. The preview on the left redraws as you go, and the spec lands with us exactly as you set it.
Frequently asked questions
Got a question about hang tab box with window? The answers below cover what we get asked most. If yours is not here, send it with a brief, message us on WhatsApp, or call +1 503-461-4788 — we reply the same working day.
Where should the window go?
Over the part of the product that explains it, not the center of the panel. We place it from a photograph and confirm on the sample.
Does the window need film?
Not always. Products that can be touched — brushes, textiles — often do better with an open window. Film keeps dust out and suits most others.
Can the window film be recyclable?
A paper-based window film keeps the pack mono-material so it recycles as paper. Standard PET film is the cheaper default.
Does a window weaken the hang tab?
It can, if it is cut close to the tab. We keep 12 mm of board between them and use a doubled tab on heavier products.
What board do you use?
18pt or heavier. A window cut in lighter board lets the panel flex on the hook.
What is the minimum order?
100 boxes.
Can the inside be printed behind the window?
Yes, and it is one of the cheapest ways to make the product read better through the window.
Can I have two windows?
Yes, front and side is common. Each removes board, so the panel design has to allow for it, and the dieline shows both.
Can the window be a shape?
Yes: a circle, an arch, a product outline. Keep the corners rounded and the shape within 8–10 mm of any edge.
Do the boxes ship flat?
Yes, with the film already applied and the box glued. They pop open and load from the end.
Will it hang straight with a window?
The hole is positioned over the center of mass, which changes when a window is cut. We work it out on the dieline and hang a filled sample to check.
Do you send a dieline?
With the quote, showing the window and the tab at true size, before anything is cut.
