Custom French Fries Boxes
A fry carton flares outward and is cut lower at the front for one reason: fingers have to reach the last third without tipping the whole thing. Every other feature of the format follows from that single usability problem.
- Formats
- Flared cartons, fry cups, scoops, bags, sharing trays
- Board
- Grease-resistant food-grade kraft or white-lined
- Shaping
- Flared opening and scooped front panel cut on the same die
Get a price for French Fries Boxes
Send the size and quantity — we reply the same working day with a price, a dieline and a date. Artwork optional at this stage.
- Free dielineThe flat drawing comes with the quote, before you commit.
- Proof before pressNothing is printed until you have seen it laid on the dieline.
- Die kept for reordersTooling is paid once. Every reorder skips straight to press.
- Quoted in four marketsUS, UK, Canada and Australia, in the delivery currency.
Flare, scoop and why straight sides fail
A straight-sided carton is comfortable to eat from until the fries drop below the halfway point, at which the customer has to tip it — usually over a table, sometimes over a car seat.
A flared carton widens toward the top so the hand enters easily, and a scooped front panel cut lower than the back means the last fries can be reached without tilting anything. Neither costs anything extra on the cutting die.
Cut the scoop on the front face, not a side. Customers hold the carton by its sides.
Formats, and where each is used
The cup is worth considering for delivery as well as drive-through. It stands up in a bag, where a carton falls over and empties.
| Flared carton | Counter service; the classic shape, flat-packs |
|---|---|
| Fry cup | Fits a car cup holder — the reason drive-through uses it |
| Fry scoop | Open-fronted; fastest to fill, least contained |
| Fry bag | Cheapest of all; no structure and it will collapse when set down |
| Sharing tray | Wide and shallow; several people reaching in at once |
Fries are the worst grease test in food service
Hot chipped potato in direct contact with board is about as aggressive as grease gets. On uncoated stock the mark reaches the outer face within a couple of minutes and transfers to hands.
Grease-resistant food-grade board is not optional here. It handles it without a PFAS treatment and keeps the carton repulpable — the board and barrier choices across the range are set out in our snack packaging notes.
Open at the top, on purpose
- Steam escaping is what keeps a fry crisp; a lid ruins them within minutes.
- Piling fries above the rim is part of how the portion is judged.
- It also means the carton offers no protection in a delivery bag.
- For delivery, a cup or a closed carton with vents beats an open one.
Flat-packed against pre-formed
Flat-packed cartons take a fraction of the storage space and cost a second or two each to open at the pass. Pre-formed cartons are ready to fill and take several times the shelf space behind a counter.
In a small kitchen, storage is usually the binding constraint rather than speed, which is why most independents buy flat and most high-volume chains do not.
Printing on something held for five minutes
A fry carton is in a customer's hand at close range, in a food court, a car or a street. It is seen by them and by everyone around them, and it costs less than almost any other branded surface you can buy.
One or two colors on kraft is the category standard and it hides grease marks better than a white board. No varnish where the food sits.
French Fries Boxes — specification
The rows that are specific to this build first, then what applies to every job we run. Anything not listed is a question, not a limit — send the brief.
This build
- Formats
- Flared cartons, fry cups, scoops, bags, sharing trays
- Board
- Grease-resistant food-grade kraft or white-lined
- Shaping
- Flared opening and scooped front panel cut on the same die
- Supply
- Flat-packed or pre-formed
- One or two colors on kraft as standard; no varnish in the food zone
- Minimum
- 100 units
On every job
- Print process
- Flexo in one to six colors, printed on the outer face only and before any lining goes on.
- Color
- Food-safe inks throughout. Kraft mutes color; a white board or liner is needed for anything photographic.
- Tolerance
- Cutting plus or minus 1 mm, and fit confirmed by filling a plain sample from your own kitchen or line.
- Tooling
- A cutting die per size, kept. Molded pulp needs a tool per shape, which is a longer lead and a larger one-off.
- Food contact
- Every board food-contact grade, with grease resistance built into the sheet and never a PFAS treatment.
- Sustainability
- Aqueous linings and unlined boards repulp with ordinary paper. PE-lined cups need cup collection, and we say which you have.
- Artwork
- Vector PDF or AI, 3 mm bleed, 4 mm safe area, fonts outlined. We check every file and send a proof before press.
- Dieline
- Supplied free with the quote, before you commit. Yours whether or not you order.
- Sample
- A plain unprinted sample at the finished size on request, for fit and construction.
- Reorders
- Skip the tooling and go straight to press at a lower unit price.
- Lead time
- Quoted with the price against your fill date rather than promised before we have seen the spec.
- Markets
- United States, United Kingdom, Canada, Australia — priced in the delivery currency, freight included.
Boards and films we build french fries boxes on
Food packaging is chosen for what the food does to it: grease, steam, heat and time. Every board here is food-contact grade, and none of them uses a PFAS treatment for grease resistance.
Food-grade virgin board
Bleached board made for direct food contact. Clean, bright, no recycled fiber and no mineral-oil risk from recovered paper.
14–24ptGrease-resistant board
Resistance built into the sheet rather than sprayed on. Holds fries, pastry and butter without darkening. PFAS-free.
16–24ptPE-lined cupstock
Board with a polyethylene film for hot and cold liquid. Microwave-safe for reheating; recycled only where cup collection exists.
260–350gsmAqueous-lined cupstock
A water-based lining instead of PE. Repulpable in ordinary paper recycling in more places, and compostable; a slightly shorter hold time.
260–320gsmGreaseproof and glassine
Dense, calendered paper that resists fat through the fiber. Wraps, liners and interleaves; breathable, so pastry stays crisp.
30–55gsmFood-grade corrugated
E and B flute with a food-contact liner, vented where steam has to leave. Pizza, catering and anything hot and heavy.
E and B fluteMolded pulp and bagasse
Fiber pressed into a shape. Holds heat, resists grease with no lining, composts, and takes only an embossed or one-color mark.
Molded to shapeRecycled board
Post-consumer fiber. Used for outers, sleeves and anything that does not touch food directly — not for direct contact.
Non-contact onlyNot sure which? Say what goes in it and where it is sold — the material follows from that. Our notes on recycled, recyclable and compostable cover which claims each stock can honestly carry.
- 01
Send what you have
A dimension, a photograph beside a ruler, or the product itself. No technical drawing needed — that part is ours.
- 02
We quote and draw
A price, a dieline and a date come back together. If a different build would suit the product better, that is in the reply too.
- 03
Approve the dieline
The flat drawing is yours to check: which panel is the front, where the folds fall, how deep the cavity really is.
- 04
Artwork on the dieline
You place your design on the flat we sent, or we place it for you, and you see a proof before anything goes to press.
- 05
A sample if you want one
A plain unprinted sample at the finished size shows fit and construction — the things a drawing cannot.
- 06
Cut, printed, shipped
The die is cut once and kept, so every reorder skips the tooling and goes straight to press at a lower unit price.
Format
Vector PDF or AI where possible. Raster artwork at 300dpi at final size, in CMYK.
Bleed
3 mm past every trim line, so a fraction of drift on the cutter never leaves a white edge.
Safe area
Keep type and anything important 4 mm inside the cut and away from every fold.
Color
Convert to CMYK before sending. Uncoated stock prints lighter; a spot color is the only exact match.
Fonts
Outline them or supply the files. A missing font substitutes silently and the proof will not match.
Barcodes
On a light, matte, unvarnished patch with the quiet zone clear — a code on gloss fails the scanner.
Not set up that way? Send it anyway — fixing a file is a short conversation, and we check every one before press. Our guide to preparing print files covers each point.
Food finishes are limited by what may touch food, and that is the point.
Food-safe inks
Printed on the outer face only. Every food pack we make uses them, laminated or not.
Uncoated kraft
No coating at all. Breathable, so pastry stays crisp, and it takes one or two colors.
Aqueous varnish
Scuff resistance without a plastic film, so the pack still repulps.
Molded emboss
A logo pressed into pulp or bagasse. No ink, nothing to rub off, and it survives grease.
Grease-resistant face
Not a finish you can see. It is in the sheet, it is PFAS-free, and it is why the print stays clean.
Matte lamination
Available on outers and sleeves that never touch food — a cake box lid, a carrier, a gift sleeve.
Not sure which suits the shelf it sells from? Say where the product is sold and we suggest one — our notes on specialty finishes show them on real boxes.
Sizing food packaging around a portion, hot: french fries boxes
Food is sized by serving, not by dimensions, and it is served hot, heaped and in a hurry. Send us the portion — or better, the box you use now with the food in it — and we size to how it is actually filled.
- Portion, heaped
- Fries, popcorn and salad are served above the rim. A box sized to a level fill looks mean and spills in a bag.
- Lid clearance
- Enough that a loaded burger or a topped cake does not touch the lid. This is the single most common complaint about a food box.
- Venting
- Hot food steams. Vents in the lid keep pastry and fries crisp; a sealed box is right only for cold food.
- Grease path
- Where the fat sits decides the board. Say if the food is fried, buttered or sauced, and whether it is held for minutes or an hour.
- Stacking in a bag
- Delivery boxes are stacked five high on a bike. The lid has to hold the box above it off the food below.
- Sample fill
- A plain box filled from your kitchen settles the size in one try, and we send one before the run.
Not sure your numbers are right? Send the product dimensions rather than the box dimensions and we work the box out — the full method is in our guide to measuring for a box.
Interactive · five steps · no sign-up
Build your French Fries Boxes in 3D
Pick a shape, type a size, choose a board and a finish. The preview on the left redraws as you go, and the spec lands with us exactly as you set it.
Frequently asked questions
Got a question about french fries boxes? The answers below cover what we get asked most. If yours is not here, send it with a brief, message us on WhatsApp, or call +1 503-461-4788 — we reply the same working day.
Why do fry cartons flare at the top?
So a hand can reach the bottom third without tipping the carton. A straight-sided one becomes unusable when half empty.
Should fries have a lid?
No — trapped steam softens them within minutes. Use a cup or a vented carton if they need containing for delivery.
Will grease show through?
On uncoated board, within minutes. Fries are the hardest grease test in food service — use grease-resistant stock.
Flat-packed or pre-formed?
Flat-packed if storage is tight, which it usually is. Pre-formed if the pass is the constraint instead.
Is a fry cup better for delivery?
Yes — it stands up in a bag, where an open carton falls over and empties.
Can the scoop shape be added to any carton?
Yes, cut on the same die at no extra cost. It is the detail most fry cartons skip.
Why do fry cartons flare at the top?
So a hand can reach the bottom third without tipping the carton. A straight-sided one becomes unusable when half empty.
Should fries have a lid?
No. Trapped steam softens them within minutes. If they need containing for delivery, use a cup or a vented carton.
Will grease show through?
On uncoated board, within minutes. Fries are the hardest grease test in food service — use grease-resistant stock.
Flat-packed or pre-formed?
Flat-packed if storage is tight, which it usually is. Pre-formed if the pass is the constraint instead.
