Custom Foldable Shoe Boxes
Custom foldable shoe boxes that arrive flat and fold in seconds — a one-piece hinged carton or a crash-lock tray with a lid — sized to your shoe and printed, from 100. Dieline and price the same working day.
A shoe box that takes up no room until there is a shoe in it
- Board
- E flute white or kraft liner; B flute for boots
- Builds
- One-piece hinged lid, crash-lock tray and lid, self-locking mailer box
- Assembly
- Under ten seconds, no glue or tape; can be re-flattened
Get a price for Foldable Shoe Boxes
Send the size and quantity — we reply the same working day with a price, a dieline and a date. Artwork optional at this stage.
- Free dielineThe flat drawing comes with the quote, before you commit.
- Proof before pressNothing is printed until you have seen it laid on the dieline.
- Die kept for reordersTooling is paid once. Every reorder skips straight to press.
- Quoted in four marketsUS, UK, Canada and Australia, in the delivery currency.
Two ways to fold
| One-piece hinged lid | Base and lid from one blank; the lid folds over and tucks; the fastest |
|---|---|
| Crash-lock tray and folding lid | The base locks as it opens; a separate lid folds; stacks like a two-piece |
| Mailer-style shoe box | Self-locking, prints inside; ships direct without an outer |
Folding without glue or tools
Corners are locked with tabs and slots; a crash-lock base snaps square with a squeeze. A packer folds one in under ten seconds with no glue and no tape. The blank is designed so the print faces out on every panel after folding, and the dieline shows the fold sequence.
Board and the stack
Our cardboard shoe boxes with a lift-off lid are the pre-folded two-piece version for stores that want boxes ready on the shelf.
- E flute with a white or kraft liner — stiff enough for a stockroom stack, folds cleanly.
- B flute for boots and heavy shoes.
- Locked corners rather than glued, so the box can be flattened again for storage.
- A lid that tucks or locks, so it does not lift in a stack.
Direct-to-consumer: the box is the mailer
A mailer-style shoe box in E flute, self-locking, printed inside and out, ships on its own to a customer. It saves an outer carton and a step at packing, and it opens at home as a branded box rather than a plain shipper with a box inside. It is built stiffer than a store box because it travels alone.
A shoe box that ships alone needs 15 mm of clearance around the shoes and a locked lid. Void fill in a shoe box is a sign it was sized wrong.
Print and the end panel
Full color on a white liner or one color on kraft, with the brand on the lid and a blank or printed size panel on the end. Inside print on the lid for a direct box. The dies are kept per size, and the size run is usually two or three boxes.
Foldable Shoe Boxes — specification
The rows that are specific to this build first, then what applies to every job we run. Anything not listed is a question, not a limit — send the brief.
This build
- Board
- E flute white or kraft liner; B flute for boots
- Builds
- One-piece hinged lid, crash-lock tray and lid, self-locking mailer box
- Assembly
- Under ten seconds, no glue or tape; can be re-flattened
- Sizing
- Two or three sizes across the run; 15 mm clearance for direct shipping
- Full color or 1 color; inside print; end size panel
- Supply
- Flat blanks, bundled
- Minimum
- 100 boxes
On every job
- Print process
- Digital below about a thousand, offset above it. One side or both, with spot colors where a match has to hold.
- Color
- CMYK as standard. Uncoated and kraft stocks print lighter and warmer; a spot color is the only exact match.
- Tolerance
- Cutting plus or minus 1 mm, creasing plus or minus 0.5 mm, confirmed on a plain sample before the run.
- Tooling
- A cutting die per size, made once and kept. Foil and emboss dies per artwork, also kept.
- Food contact
- Food-grade board and inks where the carton touches food, with the interior left plain.
- Sustainability
- Mono-material board wherever the product allows; recycled-content and FSC stocks; no claim printed the pack does not earn.
- Artwork
- Vector PDF or AI, 3 mm bleed, 4 mm safe area, fonts outlined. We check every file and send a proof before press.
- Dieline
- Supplied free with the quote, before you commit. Yours whether or not you order.
- Sample
- A plain unprinted sample at the finished size on request, for fit and construction.
- Reorders
- Skip the tooling and go straight to press at a lower unit price.
- Lead time
- Quoted with the price against your fill date rather than promised before we have seen the spec.
- Markets
- United States, United Kingdom, Canada, Australia — priced in the delivery currency, freight included.
Boards and films we build foldable shoe boxes on
A folding carton is one sheet of board, so the board is the product. These are the stocks we run for cartons, what each is good at, and where it lets you down.
Natural kraft
Unbleached folding board. Warm, hides marks, costs least. Mutes color — one or two flat colors print well, photographs do not.
250–350gsm sleeves; 14–24pt cartonsWhite SBS
Solid bleached sulfate: bright, coated, the retail carton standard. Takes accurate color and every finish. Shows scuffs sooner than kraft.
14–24ptWhite lined chipboard
A recycled gray core under a white printing face. Cheaper than SBS and slightly duller; the back of the sheet stays gray.
16–24ptKraft-look coated
A kraft face over a coated inner. The natural look with a barrier behind it — the answer where oil, grease or moisture would mark plain kraft.
14–20ptRecycled-content board
Post-consumer fiber with a gray-brown cast. Right for outers and inner components; poor for bright whites and photography.
16–22ptMicro-flute E and F
A fine corrugated layer where a carton needs structure it cannot get from board — a large panel, a heavy product, a box that ships alone.
E 1.5 mm; F 0.8 mmUncoated and textured
No clay coat, or a linen or laid grain. Print reads softer and warmer; a deboss goes deeper. Photographs do not sit well on it.
280–350gsmMetallised and pearlescent
A metallic or pearl face for a shelf that needs to catch light. Costly, and it fights a photograph — a mark or a pattern suits it better.
16–20ptNot sure which? Say what goes in it and where it is sold — the material follows from that. Our notes on recycled, recyclable and compostable cover which claims each stock can honestly carry.
- 01
Send what you have
A dimension, a photograph beside a ruler, or the product itself. No technical drawing needed — that part is ours.
- 02
We quote and draw
A price, a dieline and a date come back together. If a different build would suit the product better, that is in the reply too.
- 03
Approve the dieline
The flat drawing is yours to check: which panel is the front, where the folds fall, how deep the cavity really is.
- 04
Artwork on the dieline
You place your design on the flat we sent, or we place it for you, and you see a proof before anything goes to press.
- 05
A sample if you want one
A plain unprinted sample at the finished size shows fit and construction — the things a drawing cannot.
- 06
Cut, printed, shipped
The die is cut once and kept, so every reorder skips the tooling and goes straight to press at a lower unit price.
Format
Vector PDF or AI where possible. Raster artwork at 300dpi at final size, in CMYK.
Bleed
3 mm past every trim line, so a fraction of drift on the cutter never leaves a white edge.
Safe area
Keep type and anything important 4 mm inside the cut and away from every fold.
Color
Convert to CMYK before sending. Uncoated stock prints lighter; a spot color is the only exact match.
Fonts
Outline them or supply the files. A missing font substitutes silently and the proof will not match.
Barcodes
On a light, matte, unvarnished patch with the quiet zone clear — a code on gloss fails the scanner.
Not set up that way? Send it anyway — fixing a file is a short conversation, and we check every one before press. Our guide to preparing print files covers each point.
Every finish here is a decision about light on a shelf, not about luxury.
Matte lamination
Reads considered, hides marks, takes a ballpoint.
Gloss lamination
Lifts color; glares under shop lighting.
Soft-touch
Velvet in the hand; shows fingerprints in a bag.
Hot foil
Real metal leaf — the most reliable premium signal.
Emboss / deboss
Shape with no ink; works in the dark.
Spot UV
Gloss shapes on a matte field.
Uncoated kraft
Warm, natural, mutes color.
Textured stock
Texture in the paper; cannot scuff off.
Not sure which suits the shelf it sells from? Say where the product is sold and we suggest one — our notes on specialty finishes show them on real boxes.
Sizing a folding carton so the die comes out right: foldable shoe boxes
Measure the product, not the box it is in now. A carton is built around what has to fit inside it, assembled — cap on, lid fitted, folded if it folds — at its widest point in each direction. Send those three numbers and say which is which.
- Length x width x height
- Internal, always. External dimensions include the board and are what the carrier measures, not what the product needs.
- Clearance
- 2–3 mm a side for a snug fit; more where an insert or void fill goes in. A carton cut exactly to the product is slow to pack and transmits every knock.
- Board thickness
- Heavier board takes internal space from the product. It matters most on small boxes, where four walls of 24pt is a real share of the cavity.
- Varies between batches?
- Glass, textiles, molded parts and cured soap all do. Measure several and build to the largest.
- Cutting tolerance
- Plus or minus 1 mm on folding board. Confirmed on a plain sample before the run.
- Units
- Metric or imperial, as long as you say which. Mixing them in one spec is where mistakes happen.
Not sure your numbers are right? Send the product dimensions rather than the box dimensions and we work the box out — the full method is in our guide to measuring for a box.
Interactive · five steps · no sign-up
Build your Foldable Shoe Boxes in 3D
Pick a shape, type a size, choose a board and a finish. The preview on the left redraws as you go, and the spec lands with us exactly as you set it.
Frequently asked questions
Got a question about foldable shoe boxes? The answers below cover what we get asked most. If yours is not here, send it with a brief, message us on WhatsApp, or call +1 503-461-4788 — we reply the same working day.
How fast does it fold?
Under ten seconds, with locked corners and no glue or tape.
Can it be flattened again?
Yes, with locked rather than glued corners, for storage or reuse.
Is it as strong as a pre-assembled box?
On E flute, yes for a stockroom stack. It is the same board; only the corner construction differs.
Can it ship to a customer on its own?
The mailer-style version can, self-locking and built stiffer, with 15 mm of clearance around the shoes.
What is the minimum order?
100 boxes.
One-piece or two-piece?
One-piece hinged is fastest and cheapest; a crash-lock tray with a lid stacks like a two-piece box in a store.
Can the inside be printed?
Yes, on the lid, which matters for a box opened at home.
How much space does it save?
About ten to one: a hundred flat blanks in the space of ten assembled boxes.
Do I need a box per shoe size?
No, two or three sizes across the run, set by the largest shoe in each band.
Can the end show the size?
Yes, a blank panel for a label or a printed size on larger runs.
Do you keep the die?
Yes, per size, so reorders skip the tooling.
Do you ship outside the US?
Yes, to the United States, United Kingdom, Canada and Australia, quoted in the delivery currency.
