Custom Die-cut Folders
Custom die-cut folders in a shape of your own — a rounded edge, an angled cover, a silhouette, a tab — with pockets, a card slit and a spine, on heavy card from 100. Dieline and price the same working day.
A folder that is not a rectangle gets opened first
- Board
- 300–400 gsm coated or uncoated card; laminate optional
- Builds
- Shaped cover; one or two pockets; card slits; 3–10 mm spine; closure tab
- Shapes
- Rounded, angled, curved, window, silhouette, tabbed
Get a price for Die Cut Folders
Send the size and quantity — we reply the same working day with a price, a dieline and a date. Artwork optional at this stage.
- Free dielineThe flat drawing comes with the quote, before you commit.
- Proof before pressNothing is printed until you have seen it laid on the dieline.
- Die kept for reordersTooling is paid once. Every reorder skips straight to press.
- Quoted in four marketsUS, UK, Canada and Australia, in the delivery currency.
Shapes that work on a folder
| Rounded corners | The quietest change; survives a bag better than square |
|---|---|
| Angled or curved front edge | The cover cut short or on a diagonal; the inside shows |
| Cut-out window | A shape in the cover — a logo, a circle — revealing the sheet inside |
| Silhouette | The whole folder in an outline: a house, a leaf, a product |
| Tabbed | A tab on the cover or the pocket for a title or an index |
What a die-cut folder still needs to do
Our embossed presentation folders cover the relief finishes that sit well on a shaped cover.
- Hold sheets: a pocket, glued on two sides, sized to A4 or letter plus 3 mm.
- Hold a card: a slit or a pair of slits in the pocket.
- Hold a set: a scored spine of 3–10 mm so the cover closes over twenty or fifty sheets.
- Stand a mailing: a closure tab or a band if it goes in the post.
Card and the cut
300–400 gsm coated or uncoated card, laminated if it is handled; a shaped edge needs a heavier card than a straight one because it has less support. A silhouette is cut on a die made once and kept, so a reprint is print only. Narrow necks and sharp points are rounded on the dieline so they do not tear.
A cut-out window in the cover shows whatever is on the first sheet. Design the first sheet with the window, or it shows a paragraph.
Print, and the shape doing the work
A shaped folder needs less print than a rectangular one. One color and a strong shape read as designed; full color on a silhouette can look busy. Foil on the cut edge, a deboss on the cover, a color inside that shows at the angled edge — the finish follows the shape.
Who orders shaped folders
Agencies and studios for proposals, estate agents for property packs, schools and universities for prospectuses, and product brands for a press kit in the product's outline. Runs of 100 to 500; the die is kept and used for years.
Die Cut Folders — specification
The rows that are specific to this build first, then what applies to every job we run. Anything not listed is a question, not a limit — send the brief.
This build
- Board
- 300–400 gsm coated or uncoated card; laminate optional
- Builds
- Shaped cover; one or two pockets; card slits; 3–10 mm spine; closure tab
- Shapes
- Rounded, angled, curved, window, silhouette, tabbed
- 1 color to full color; foil, deboss; inside color
- Tooling
- Die made once per shape, kept
- Sizing
- A4, letter and custom; pocket to sheet plus 3 mm
- Minimum
- 100 folders
On every job
- Print process
- Digital below about a thousand, offset above it. One side or both, with spot colors where a match has to hold.
- Color
- CMYK as standard. Uncoated and kraft stocks print lighter and warmer; a spot color is the only exact match.
- Tolerance
- Cutting plus or minus 1 mm, creasing plus or minus 0.5 mm, confirmed on a plain sample before the run.
- Tooling
- A cutting die per size, made once and kept. Foil and emboss dies per artwork, also kept.
- Food contact
- Food-grade board and inks where the carton touches food, with the interior left plain.
- Sustainability
- Mono-material board wherever the product allows; recycled-content and FSC stocks; no claim printed the pack does not earn.
- Artwork
- Vector PDF or AI, 3 mm bleed, 4 mm safe area, fonts outlined. We check every file and send a proof before press.
- Dieline
- Supplied free with the quote, before you commit. Yours whether or not you order.
- Sample
- A plain unprinted sample at the finished size on request, for fit and construction.
- Reorders
- Skip the tooling and go straight to press at a lower unit price.
- Lead time
- Quoted with the price against your fill date rather than promised before we have seen the spec.
- Markets
- United States, United Kingdom, Canada, Australia — priced in the delivery currency, freight included.
Boards and films we build die cut folders on
A folding carton is one sheet of board, so the board is the product. These are the stocks we run for cartons, what each is good at, and where it lets you down.
Natural kraft
Unbleached folding board. Warm, hides marks, costs least. Mutes color — one or two flat colors print well, photographs do not.
250–350gsm sleeves; 14–24pt cartonsWhite SBS
Solid bleached sulfate: bright, coated, the retail carton standard. Takes accurate color and every finish. Shows scuffs sooner than kraft.
14–24ptWhite lined chipboard
A recycled gray core under a white printing face. Cheaper than SBS and slightly duller; the back of the sheet stays gray.
16–24ptKraft-look coated
A kraft face over a coated inner. The natural look with a barrier behind it — the answer where oil, grease or moisture would mark plain kraft.
14–20ptRecycled-content board
Post-consumer fiber with a gray-brown cast. Right for outers and inner components; poor for bright whites and photography.
16–22ptMicro-flute E and F
A fine corrugated layer where a carton needs structure it cannot get from board — a large panel, a heavy product, a box that ships alone.
E 1.5 mm; F 0.8 mmUncoated and textured
No clay coat, or a linen or laid grain. Print reads softer and warmer; a deboss goes deeper. Photographs do not sit well on it.
280–350gsmMetallised and pearlescent
A metallic or pearl face for a shelf that needs to catch light. Costly, and it fights a photograph — a mark or a pattern suits it better.
16–20ptNot sure which? Say what goes in it and where it is sold — the material follows from that. Our notes on recycled, recyclable and compostable cover which claims each stock can honestly carry.
- 01
Send what you have
A dimension, a photograph beside a ruler, or the product itself. No technical drawing needed — that part is ours.
- 02
We quote and draw
A price, a dieline and a date come back together. If a different build would suit the product better, that is in the reply too.
- 03
Approve the dieline
The flat drawing is yours to check: which panel is the front, where the folds fall, how deep the cavity really is.
- 04
Artwork on the dieline
You place your design on the flat we sent, or we place it for you, and you see a proof before anything goes to press.
- 05
A sample if you want one
A plain unprinted sample at the finished size shows fit and construction — the things a drawing cannot.
- 06
Cut, printed, shipped
The die is cut once and kept, so every reorder skips the tooling and goes straight to press at a lower unit price.
Format
Vector PDF or AI where possible. Raster artwork at 300dpi at final size, in CMYK.
Bleed
3 mm past every trim line, so a fraction of drift on the cutter never leaves a white edge.
Safe area
Keep type and anything important 4 mm inside the cut and away from every fold.
Color
Convert to CMYK before sending. Uncoated stock prints lighter; a spot color is the only exact match.
Fonts
Outline them or supply the files. A missing font substitutes silently and the proof will not match.
Barcodes
On a light, matte, unvarnished patch with the quiet zone clear — a code on gloss fails the scanner.
Not set up that way? Send it anyway — fixing a file is a short conversation, and we check every one before press. Our guide to preparing print files covers each point.
Every finish here is a decision about light on a shelf, not about luxury.
Matte lamination
Reads considered, hides marks, takes a ballpoint.
Gloss lamination
Lifts color; glares under shop lighting.
Soft-touch
Velvet in the hand; shows fingerprints in a bag.
Hot foil
Real metal leaf — the most reliable premium signal.
Emboss / deboss
Shape with no ink; works in the dark.
Spot UV
Gloss shapes on a matte field.
Uncoated kraft
Warm, natural, mutes color.
Textured stock
Texture in the paper; cannot scuff off.
Not sure which suits the shelf it sells from? Say where the product is sold and we suggest one — our notes on specialty finishes show them on real boxes.
Sizing a folding carton so the die comes out right: die cut folders
Measure the product, not the box it is in now. A carton is built around what has to fit inside it, assembled — cap on, lid fitted, folded if it folds — at its widest point in each direction. Send those three numbers and say which is which.
- Length x width x height
- Internal, always. External dimensions include the board and are what the carrier measures, not what the product needs.
- Clearance
- 2–3 mm a side for a snug fit; more where an insert or void fill goes in. A carton cut exactly to the product is slow to pack and transmits every knock.
- Board thickness
- Heavier board takes internal space from the product. It matters most on small boxes, where four walls of 24pt is a real share of the cavity.
- Varies between batches?
- Glass, textiles, molded parts and cured soap all do. Measure several and build to the largest.
- Cutting tolerance
- Plus or minus 1 mm on folding board. Confirmed on a plain sample before the run.
- Units
- Metric or imperial, as long as you say which. Mixing them in one spec is where mistakes happen.
Not sure your numbers are right? Send the product dimensions rather than the box dimensions and we work the box out — the full method is in our guide to measuring for a box.
Interactive · five steps · no sign-up
Build your Die Cut Folders in 3D
Pick a shape, type a size, choose a board and a finish. The preview on the left redraws as you go, and the spec lands with us exactly as you set it.
Frequently asked questions
Got a question about die cut folders? The answers below cover what we get asked most. If yours is not here, send it with a brief, message us on WhatsApp, or call +1 503-461-4788 — we reply the same working day.
What shapes can a folder be?
Rounded, angled or curved edges, a cut-out window, a full silhouette, or a tab — anything that can be die-cut from card with the pocket still working.
Does a shaped folder still hold documents?
Yes, with a pocket sized to the sheet plus 3 mm, a card slit and a spine if needed.
Can the cover have a window?
Yes, showing the first sheet. Design the first sheet with the window in mind.
What card do you use?
300–400 gsm; a shaped edge needs heavier card than a straight one.
Is the die kept?
Yes, per shape, so reprints skip the tooling.
What is the minimum order?
100 folders.
Can I have a spine for many sheets?
Yes, scored to 3–10 mm for twenty to seventy sheets.
Can it be mailed?
Yes, with a closure tab or a band, and a shape without sharp points.
Do shaped folders need full color?
Usually not. One color and a strong shape read as designed; foil or a deboss adds the finish.
Will sharp points tear?
They are rounded on the dieline so they do not.
Do folders ship flat?
Yes, with the pocket glued, and fold at the desk.
Do you ship outside the US?
Yes, to the United States, United Kingdom, Canada and Australia, quoted in the delivery currency.
